| Frequency Range | 30MHz-6GHz |
|---|---|
| Instantaneous Bandwidth | Maximum 1000MHz |
| Transmitter Antenna Performance | 30MHz-6GHz Whip Antenna 、0.8GHz-6GHz Log Periodic Antenna |
| Amplifier Output Performance | Output Power 10W |
| Analogue Radar Signal | Continuous Wave, Regular Pulse, Frequency Agility, Etc. 、Frequency Range 30MHz-6GHz 、Frequency Accuracy 10-6* Center Frequency |
| Operating Frequency | 2GHz-18GHz |
|---|---|
| Instantaneous Operating Bandwidth | 400MHz、1000MHz |
| Interference Transmit Performance | Transmit Power ≥5W Continuous Wave 、Transmit Power (Single Channel): ≥ 10W Continuous Wave |
| Reconnaissance Reception Performance | Receiver Sensitivity：≤-60dBm |
| Interference Simulation Performance | Noise Suppression Interference, Coherent Suppression Interference, Deception Interference, Combination Interference |
| Operating Frequency | 2GHz-4GHz |
|---|---|
| Instantaneous Operating Bandwidth | 400MHz |
| Transceiver Antenna Performance | Conical Spiral Antenna, Typical Gain 10dBi 、Dual Polarized Horn Antenna, Gain Range 610dBi |
| Reconnaissance Reception Performance | Receiver Sensitivity ≤ -60dBm |
| Interference Transmit Performance | Transmit Power (Single Channel) ≥ 10W Continuous Wave |
| Frequency Range | 75MHz-105MHz |
|---|---|
| Instantaneous Bandwidth | ≥30MHz |
| Output Power | 0dBm-20dBm |
| Simulate Number Of Targets | 1Target- 5 Targets |
| Simulate Target Delay | 120m-7000m |
