Adjustment Pitch Active Phased Array Radar For Low Altitude Flying Targets

LT-X07A Low Altitude Warning Radar + LT-UJ830Q Omni-Directional UAV Jammer (Optional)

Product Introduction:

The LT-X07A radar is a low-altitude surveillance and reconnaissance equipment thatsearches and tracks moving ground targets, low-altitude helicopters, missiles, UAVs, andsea surface targets, and can perfomm preliminary classification and recognition. The LT-X07Aradar adopts an active phased array radar system with elevation dimension and azimuthmechanical scanning, Pitch single pulse angle measurement, suitable for single radar fullazimuth coverage. The low alitude security radar system can detect and extract targetinformation in complex environments with strong ground clutter, providing informationsupport for combat personnel.

The omnidirectional multi-band jamming antenna system adopts multiple cylindrical spiral antennas, and its transmission frequency band can almost cover the communication frequency band of UAVs in the market, including 3 flat panel antennas and 1 PCB antenna. It can effectively jam targets within the operating range of the antenna, and the jamming range is determined by the anti-jamming capability of the UAVs. This jammer adopts an omnidirectional jamming system, which can effectively maintain the airspace security of key areas.

Product Features:
1, Strong resistance to environmental clutter.
2, Strong ability to detect small and slow targets.
3, With a pitch adjustment device, can adjust the angle of the antenna, applicable to a variety of different geographical conditions.
4, Solves the technical difficulties of tracking and recognizing multi-targets in the background noisy environment.

5, The jammer adopts omnidirectional jamming system.
6, The pitch transmission section uses a worm gear transmission which is self-locking in the event of a power failure.
7, The internal industrial grade (military grade optional) embedded intelligent control system can realize the stable control of the turntable.
